Greenhouse Polyethylene Film Blowing Machine For Agricultur 3000mm Width

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	Xiaohai
Certification:	CE
Model Number:	SJ-B

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Packaging Details:	Seaworthy Package
Delivery Time:	30 days
Payment Terms:	30 days after receiving 30% deposit.
Supply Ability:	30 sets/month

Contact Now

Detailed Product Description

Highlight:

blown film extrusion machine

film blowing machinery

Greenhouse Polyethylene Film Blowing Machine For Agriculture 3000mm Width

Quick Detail:

1. Can make film width 3000mm
2. Double rewinder, with rotary head

Condition	New
Application	Film
Plastic Processed	PE
Blow Moulding Type	Extrusion Blow Moulding
Automatic	Yes
Place of Origin	Zhejiang, China (Mainland)
Brand Name	Xiaohai
Model Number	SJ-B plastic film blowing machine
Voltage	380v or 220V
Power(KW)	15kw
Certification	CE
Warranty	one year for mechanical parts,half year for electric parts.the service is for whole life, once you asked the spare parts,we can send immediately,but you need to pay the courier fee.
After-sales Service Provided	Engineers available to service machinery overseas

Description:

Both cylinder and screw of the extruder are made of high quality alloy steel through nitration and precision finishing with the best hardness and corrosion resistance. Scientifically designed, this machine set has two heads for one extruder with such advantages as increasing production capacity, saving energy, labour and workshop area, etc.

Applications:

1. PE Film Extruder is used for blowing the plastic film of low density polyethylene(LDPE), high density polythylene(HDPE) and linear low density polyethylene(LLDPE) etc.

2. The PE film is widely used for packing bag,such as T-shirt bag,shopping bag,clothing bag,garbage bag and agriculture covering film etc

Specifications:

Model No.	SJ-B100	SJ-B110	SJ-B120
Screw Diameter	100mm	110mm	120mm
Screw Ratio(L/D)	28:1	28:1	28:1
Max.Folding Width of Film	2000mm	2500mm	3000mm
Single Side Thickness of Film	0.02-0.08mm	0.02-0.08mm	0.02-0.08mm
Power of Main Motor	55KW	75KW	90KW
Output	160kg/h	190kg/h	220kg/h
Total Power	88Kw	106Kw	126Kw
Weight of Machine	60000kg	9000kg	12000kg
Dimension(mm)	8000x3200x7600	9000x3700x8700	1000x4200x9800
