4200RPM Rolling Door Opener Motor Brushed Low Noise and Long Lifetime 24VDC

Product Details:

Place of Origin:	Zhejiang, China
Brand Name:	CIROLLA
Certification:	CE/CCC/ SGS
Model Number:	80ZYT-1

Payment & Shipping Terms:

Minimum Order Quantity:	500PCS
Price:	Consultation get the latest price
Packaging Details:	Standard,10pcs/carton, weight 2.5kg
Delivery Time:	25-30days
Payment Terms:	T/T,L/C, Western Union
Supply Ability:	50,000pcs/month

Contact Now

Detailed Product Description

Motor Type:	Brushed	Reduction Type:	Worm Gear
Rated Voltage:	12V	Rated Power:	180W
Style:	Roller Shutter Door Motor
Highlight:	rolling shutter motor , garage roller door motor

4200RPM Rolling Door Opener Motor Brushed with Low Noise and Long Lifetime 24VDC

Description:

A roller shutter, roller door or sectional overhead door is a type of door or window shutter consisting of many horizontal slats (or sometimes bars or web systems) hinged together. The door is raised to open it and lowered to close it. On large doors, the action may be motorized. It provides protection against wind and rain. In shutter form, it is used in front of a window and protects the window from vandalism and burglary attempts.

Applications:

Roller shutters have many applications, including doors for vans, garages, kitchens, schools, prisons and warehouses. In some parts of the world, roller shutters are subsidized by local governments due to the inherent security benefits. In areas that are frequently exposed to inclement weather, roller shutters are used as a method of insulation and can protect windows against hail damage.

4200RPM Rolling Door Opener Motor Brushed Low Noise and Long Lifetime 24VDC 0

Specifications:

Performance data:

Type	Brush
Voltage	12VDC
Power	180W
No load Speed	4200rpm
No load Current	3.0A
On load Speed	3300rpm
On load Current	19.5A
Stall torque	≥655m.Nm
Protection class	IP44
Weight	2.0kg

Characteristic curves:

State	Voltage	Current	Pin	Torque	Speed	Pout	Eff
State	V	A	W	mN.m	rpm	W	%
Speed_max	12.02	2.391	28.76	0.1	3444	0.05	0.1
Eff_max	11.90	10.01	119.2	253.8	2759	73.31	61.4
Pout_max	11.66	23.12	269.6	650.3	1909	129.9	48.1
Torque_max	11.65	23.26	271.2	655.3	1879	128.9	47.5
End	11.65	23.26	271.2	655.3	1879	128.9	47.5

Competitive Advantage:

Courtesy light - Comes on automatically when the door is in use. The light will stay on for approximately 3 minutes, then turns off automatically.

Automatic Safety Reverse – Garage Ace sensors when someone or something is in the way, and reverses automatically.

Safe and Secure - High security rolling code transmitters. Two remotes supplied.

Manual Override - Motor can be easily disengaged in the event of power failure for manual operation of door.

Handy Wall Switch - Door can be operated from switch on interior mounted control box independently of remote transmitter.

Automatic Run Time - If motor is activated while disengaged, the auto run time will turn motor off after 30 seconds

Quiet Operation - No need to let the neighborhood know when you come and go!

DIY Installation - Step-by-step instructions will guide you through installation. The opener can be installed on the left or right-hand side of the door.

Outline drawings of motor:
